Energy Efficient DTH Hammer Bits Mission30 DTH Drilling Rigs For Geological Exploration

Name: Energy Efficient DTH Hammer Bits Mission30 DTH Drilling Rigs For Geological Exploration
Brand: New Diamond
Price: 1 USD

Brand Name : New Diamond

Model Number : Mission30

Certification : ISO9001:2008

Place of Origin : Hunan, China (Mainland)

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : According to order quantity

Delivery Time : 5-8 work days

Packaging Details : Carton packaging and wooden box packing

Type : Drill Bit

Processing Type : Forging

Use : Ore Mining

Color : Required

Button shape : Spherical/Ballistic/parabolic/sharp/falt bottons

Usage : Quarrying& Ore Mining& Well Drilling

Contact Now

Description

DTH drilling rigs are widely used in the large-aperture open-hole rock drilling project. DTH drill bit with drilling performance is stable, easy to use grinding, and the price is reasonable and other factors by the user. At present, most of the DTH drill bits adopt the ball-type alloy head and the spline-shaped tail handle. Drill alloy can be divided according to the shape of hemispherical teeth, tapered teeth, parabolic teeth and other types. Hemispherical teeth with high load capacity, good wear resistance, suitable for drilling hard, hard and abrasive rock; tapered teeth and parabolic teeth drilling speed, suitable for drilling hard and non-abrasive rocks. DTH drill bits can also be used with the teeth (gage, drilling teeth) with the ball, the core teeth (broken broken rock) with tapered teeth, parabolic teeth in the form of compound cloth teeth, can reach under a variety of types of rocks quickly The purpose of drilling.

Applications

It is mainly used in geological exploration, coal mine, water conservancy and hydropower, highway, railway, bridge, construction and so on.

Specifications

Mission series	Head shape	Diameter mm	Number of vents	NO X button diamter			weight (KG)
				Toothed	Gauge	Front
Mission30	Flat Face Bit	90	2	Round Button	8XØ12	6XØ12
	Convex Face	100	2	Round Button +Ballistic Button	6XØ14	3XØ13+2XØ12
WE can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

Feature Advantage

1. Long life span: the wear-resist of tungsten carbides is 10-20 times higher compared with other similar materials, which greatly extends the life of the carbide bits;
2. High drilling efficiency: the high grade hardness of the carbides can always stay sharp, which could increase the drilling speeds too;
3. New Diamond's bits are widely used in different rock formations like carbonate rock,limestone,chalk rock, clay rock,siltstone and sandstone;
4. It can greatly reduce the drilling cost, because of its high drilling speed and life span, which reduces the times to changes bits in the drilling service.

The appearance of the picture is different from that of the actual product, and the actual product is the standard.
